Niviuk Qubik 2







Size			21	23	25	27
TOTAL WEIGHT IN FLIGHT	MIN-MAX	kg	70-120	80-140	100-160	110-180
CELLS	NUMBER		55	55	55	55
ASPECT RATIO	FLAT		5.5	5.5	5.5	5.5
	PROJECTED		4.32	4.32	4.32	4.32
AREA	FLAT	m²	21	23	25	27
	PROJECTED	m²	18.27	20.01	21.75	23.49
SPAN	FLAT	m	10.75	11.25	11.73	12.19
CHORD	MAXIMUM	m	2.41	2.52	2.63	2.73
LINES	TOTAL	m	269	282	295	307
	MAIN		2+1/4/1+2	2+1/4/1+2	2+1/4/1+2	2+1/4/1+2
RISERS	NUMBER		A+A’/B/C’+C	A+A’/B/C’+C	A+A’/B/C’+C	A+A’/B/C’+C
	TRIMMERS	mm	150	150	150	150
GLIDER WEIGHT		kg	5.97*	6.25	6.55*	6.90*
CERTIFICATION			DGAC/EN 926-1	DGAC/EN 926-1	DGAC/EN 926-1	DGAC/EN 926-1

* To be confirmed

The total weight of the wing may differ ±2% due to variations in the weight of the fabric supplied by the manufacturers.

Colours

Standard colours: Motmot, Rubi, Jaspe



Package

• Niviuk Qubik 2
• Niviuk inner bag
• Niviuk compression strap
• Niviuk risers cover
• Niviuk repair kit

Note: A backpack is not included in the price (optional extra. to give you the choice).

Qubik 2: THE STATE OF INDEPENDENCE

Optimised manoeuvrability

The handling of the Qubik 2 has been significantly improved. The glider’s response to the pilot’s inputs is precise and progressive, facilitating turns with direct and comfortable control at every stage of flight. It is ideal for a dynamic and fluid experience.

Increased speed range

The Qubik 2 features a trimmer and speed-bar system that improves control at high speeds, offering greater stability and reaching higher speeds compared to the previous model.

Improved performance

It offers superior performance thanks to a more aerodynamic design. The aerofoil has been optimised, the number of cells reduced and the lineset simplified, to ensure the perfect balance between stability, comfort and performance on long flights in all conditions.

Easy launches and landings

The Qubik 2 inflates progressively, facilitating a controlled launch with minimal pilot effort and no pitching movements.

During landing, it allows precise speed control, ensuring smooth and safe manoeuvres and turns at all times.

Target

Cross-country

A stable and safe progression wing for those distance flights you´ve always wanted to do. The Qubik 2 is ideal to take you out of your comfort zone and encourage you to progress with longer flights and extra speed.

Recreational flying

You can use it for any of your recreational and daily flights. The Qubik 2 has been designed to enjoy everyday and distance flying with more direct and efficient handling. Explore new routes with confidence.

DRS incorporated

Mini-ribs have been incorporated into the trailing edge for a cleaner profile, eliminating external seams and protecting them from wear when in contact with the ground. DRS technology allows for reduced drag and improved brake pressure, making it smoother and reducing the pressure needed to manoeuvre.

Reflex profile

The reflex of the profile curvature and arc have been optimised to improve pitch stability. The flight angles have been widened, increasing the speed range and adapting the wing to the demands of this category.

More efficient lines

The lineset has been simplified from four to three lines, compared to the previous model. This update not only lightens the glider, but also simplifies pre-flight preparation and significantly reduces drag, thus maximising performance and efficiency.

Optimised internal design

The internal structure of the Qubik 2 has been redesigned, optimising ribs, diagonals and attachment points. In addition, air inlets with RAM technology ensure uniform and constant internal pressure, improving the stability and uniformity of the glider. This increases performance and optimises fuel consumption.

Nitinol reinforcements

The Qubik 2 is very durable thanks to the integrated Nitinol rods in the leading edge, which retain the optimal shape of the wing even after compact packing.

Uniform leading edge

The leading edge of the Qubik 2 incorporates an additional longitudinal seam and uses 3DP technology to ensure uniform, crease-free tension, resulting in a perfectly smooth and aerodynamic profile.
